Serverless Cloud Run Development: Challenge Lab

February 7, 2021|Cloud Run, GCP, Qwiklabs|電腦編程

This article provide a guidance to complete GSP328 Serverless Cloud Run Development: Challenge Lab. It won’t provide steps directly, only tips to finish the lab.

The challenge contains 7 tasks. As it has staging and production environment, so actually is 3 different sets of tasks.

Provision the Qwiklabs environment

run those commands to set config and checkout files

Task 1:

Assessment

Build an image using Cloud Build
Deploy a Cloud Run service as an unauthenticated service
Test service responds when the endpoint is accessed

1
2
3
4
5
6
7
8
+-----------------+-----------------------------------+
|      FIELD      |               VALUE               |
+-----------------+-----------------------------------+
| Billing Image   | billing-staging-api:0.1           |
| Billing Service | public-billing-service            |
| Authentication  | unauthenticated                   |
| Code            | pet-theory/lab07/unit-api-billing |
+-----------------+-----------------------------------+


  1. gCloud build command reference: https://cloud.google.com/sdk/gcloud/reference/beta/builds/submit
Shell
1
2
3
cd ~/<CODE>
gcloud builds submit \
--tag gcr.io/$GOOGLE_CLOUD_PROJECT/<BILLING_IMAGE>


2. gCloud deploy command reference:

  • https://cloud.google.com/sdk/gcloud/reference/run/deploy
  • https://cloud.google.com/sdk/gcloud/reference/run/deploy#–[no-]allow-unauthenticated
Shell
1
2
3
gcloud run deploy <SERVICE> \
--image gcr.io/$GOOGLE_CLOUD_PROJECT/<BILLING_IMAGE> \
--<AUTHENTICATED>


3. optional: click on the Service URL  in cloud shell, or curl manually. e.g. curl https://public-billing-service-XXXXXXX.a.run.app

Task 2:

Same as task 1, with different values.

1
2
3
4
5
6
7
8
+----------------+-------------------------------------------+
|     FIELD      |                   VALUE                   |
+----------------+-------------------------------------------+
| Image Name     | frontend-staging:0.1                      |
| Service Name   | frontend-staging-service                  |
| Authentication | unauthenticated                           |
| Code           | pet-theory/lab07/staging-frontend-billing |
+----------------+-------------------------------------------+


Task 3:

1
2
3
4
5
6
7
8
+----------------+--------------------------------------+
|     FIELD      |                VALUE                 |
+----------------+--------------------------------------+
| Image Name     | billing-staging-api:0.2              |
| Service Name   | private-billing-service              |
| Authentication | authenticated                        |
| Code           | pet-theory/lab07/staging-api-billing |
+----------------+--------------------------------------+


  1. Delete the existing Billing Service
Shell
1
2
cd ~/<CODE>
gcloud beta run services delete public-billing-service


2. Build an image using Cloud Build: similar to task 1

3. Deploy the image to Cloud Run requiring authentication: similar to above, just be aware this time is authenticated. --no-allow-unauthenticated

4. Test service:

Shell
1
2
3
4
BILLING_SERVICE=private-billing-service
BILLING_URL=$(gcloud run services describe $BILLING_SERVICE \
  --format "value(status.URL)")
curl -X get -H "Authorization: Bearer $(gcloud auth print-identity-token)" $BILLING_URL


Task 4:

1
2
3
4
5
6
+-----------------+---------------------------+
|      FIELD      |           VALUE           |
+-----------------+---------------------------+
| Service Account | billing-service-sa        |
| Display Name    | Billing Service Cloud Run |
+-----------------+---------------------------+


  1. create service account reference: https://cloud.google.com/iam/docs/creating-managing-service-accounts#creating
Shell
1
gcloud iam service-accounts create <SERVICE_ACOUNT> --display-name "<DISPLAY_NAME>"


Task 5:

1
2
3
4
5
6
7
8
9
+-----------------+-----------------------------------+
|      FIELD      |               VALUE               |
+-----------------+-----------------------------------+
| Image Name      | billing-prod-api:0.1              |
| Service Name    | billing-prod-service              |
| Authentication  | authenticated                     |
| Code            | pet-theory/lab07/prod-api-billing |
| Service Account | billing-service-sa                |
+-----------------+-----------------------------------+


  1. Deploy the image to Cloud Run & Enable Authentication
Shell
1
2
cd ~/<CODE>
## similar to task 3 build and deploy command above


2. Enable Service Account

https://cloud.google.com/sdk/gcloud/reference/run/services/add-iam-policy-binding

Shell
1
2
3
gcloud run services add-iam-policy-binding <SERVICE_NAME> \
  --member=serviceAccount:<SERVICE_ACCOUNT>@$GOOGLE_CLOUD_PROJECT.iam.gserviceaccount.com \
  --role=roles/run.invoker


3. optional: Test service url: lab instructions URL  is case sensitive.

Shell
1
2
3
4
5
6
PROD_BILLING_SERVICE=private-billing-servicePROD_BILLING_URL=$(gcloud run services \
    describe $PROD_BILLING_SERVICE \
    --format "value(status.URL)")
curl -X get -H "Authorization: Bearer \
    $(gcloud auth print-identity-token)" \
    $PROD_BILLING_URL


Task 6:

1
2
3
4
5
6
+-----------------+-----------------------------------+
|      FIELD      |               VALUE               |
+-----------------+-----------------------------------+
| Service Account | frontend-service-sa               |
| Display Name    | Billing Service Cloud Run Invoker |
+-----------------+-----------------------------------+


  1. same command as Task 4

Task 7:

1
2
3
4
5
6
7
8
9
+-----------------+----------------------------------------+
|      FIELD      |                 VALUE                  |
+-----------------+----------------------------------------+
| Image Name      | frontend-prod:0.1                      |
| Service Name    | frontend-prod-service                  |
| Authentication  | unauthenticated                        |
| Code            | pet-theory/lab07/prod-frontend-billing |
| Service Account | frontend-service-sa                    |
+-----------------+----------------------------------------+


  1. Deploy the image to Cloud Run & Enable Authentication: refer to Task 5
Shell
1
2
cd ~/<CODE>
## similar to task 5 build and deploy command above


2. Enable Service Account: similar to task 5

Shell
1
2
3
gcloud run services add-iam-policy-binding <SERVICE_NAME> \
  --member=serviceAccount:<SERVICE_ACCOUNT>@$GOOGLE_CLOUD_PROJECT.iam.gserviceaccount.com \
  --role=roles/run.invoker


3. optional: click on URL printed in cloud shell to verify endpoint access

Congratulations

After that you should be able to finish this challenge lab and obtain a skill badge:
