Recently I was assigned to a task about adding a file upload feature to a existing nginx server on CentOS. Nginx was chosen years ago because it simply handles some static files only. If the file upload was a requirement, using apache is simpler as computation power isn’t a constraint in our case.
Background
- CentOS 7
- nginx 1.10.2
- nginx-upload-module
- ngx_http_auth_pam_module
Compile Dynamic modules
Download upload and auth pam module source code. Then find out the current nginx version, download the source code and compile modules
## download module source code $ wget https://github.com/sto/ngx_http_auth_pam_module/archive/master.zip -O ngx_http_auth_pam_module.zip $ unzip ngx_http_auth_pam_module.zip $ mv ngx_http_auth_pam_module-master ngx_http_auth_pam_module $ wget https://github.com/vkholodkov/nginx-upload-module/archive/master.zip -O nginx-upload-module.zip $ upzip nginx-upload-module.zip $ mv nginx-upload-module-master nginx-upload-module ## modify the "config" file to support dynamic module, ## see https://github.com/vkholodkov/nginx-upload-module/issues/78 ## install compile dependencies $ sudo yum -y install pcre-devel zlib-devel pam-devel libxslt-devel perl-ExtUtils-Embed GeoIP-devel \ redhat-rpm-config openssl-devel gd-devel gperftools-devel gcc-c++ ## find out the current version of nginx $ nginx -v ## download source code $ wget http://nginx.org/download/nginx-1.10.2.tar.gz ## list all compile parameters $ nginx -V ## e.g. configure arguments: --prefix=/usr/share/nginx --sbin-path=/usr/sbin/nginx --modules-path=/usr/lib64/nginx/modules --conf-path=/etc/nginx/nginx.conf --error-log-path=/var/log/nginx/error.log --http-log-path=/var/log/nginx/access.log --http-client-body-temp-path=/var/lib/nginx/tmp/client_body --http-proxy-temp-path=/var/lib/nginx/tmp/proxy --http-fastcgi-temp-path=/var/lib/nginx/tmp/fastcgi --http-uwsgi-temp-path=/var/lib/nginx/tmp/uwsgi --http-scgi-temp-path=/var/lib/nginx/tmp/scgi --pid-path=/run/nginx.pid --lock-path=/run/lock/subsys/nginx --user=nginx --group=nginx --with-file-aio --with-ipv6 --with-http_ssl_module --with-http_v2_module --with-http_realip_module --with-http_addition_module --with-http_xslt_module=dynamic --with-http_image_filter_module=dynamic --with-http_geoip_module=dynamic --with-http_sub_module --with-http_dav_module --with-http_flv_module --with-http_mp4_module --with-http_gunzip_module --with-http_gzip_static_module --with-http_random_index_module --with-http_secure_link_module --with-http_degradation_module --with-http_slice_module --with-http_stub_status_module --with-http_perl_module=dynamic --with-mail=dynamic --with-mail_ssl_module --with-pcre --with-pcre-jit --with-stream=dynamic --with-stream_ssl_module --with-google_perftools_module --with-debug --with-cc-opt='-O2 -g -pipe -Wall -Wp,-D_FORTIFY_SOURCE=2 -fexceptions -fstack-protector-strong --param=ssp-buffer-size=4 -grecord-gcc-switches -specs=/usr/lib/rpm/redhat/redhat-hardened-cc1 -m64 -mtune=generic' --with-ld-opt='-Wl,-z,relro -specs=/usr/lib/rpm/redhat/redhat-hardened-ld -Wl,-E' ## reuse the configs output from "nginx -V", now compile http auth pam module $ tar zxvf nginx-1.10.2.tar.gz $ cd nginx-1.10.2 $ ./configure --prefix=/usr/share/nginx ........... -specs=/usr/lib/rpm/redhat/redhat-hardened-ld -Wl,-E' \ --add-dynamic-module=../ngx_http_auth_pam_module $ make modules ## upload to to server $ scp objs/ngx_http_auth_pam_module.so user@host:/usr/lib64/nginx/modules/ ## repeat for nginx-upload-module $ ./configure --prefix=/usr/share/nginx ........... -specs=/usr/lib/rpm/redhat/redhat-hardened-ld -Wl,-E' \ --add-dynamic-module=../nginx-upload-module $ make modules $ scp objs/ngx_http_upload_module.so user@host:/usr/lib64/nginx/modules/ ## create configs echo 'load_module "/usr/lib64/nginx/modules/ngx_http_auth_pam_module.so";' > /usr/share/nginx/modules/mod-http-auth-pam.conf echo 'load_module "/usr/lib64/nginx/modules/ngx_http_upload_module.so";' > /usr/share/nginx/modules/mod-http-upload.conf ## to validate config $ nginx -tc /etc/nginx/nginx.conf
